Wright Flow Technologies Revolution R0150X - Flushing Positions Size 7

Page 21
3.8.1 Flushing Positions Size 7
A
B
C
D
E
F
Connection
MM
Inch
MM
Inch
MM
Inch
Degrees
MM
Inch
MM
Inch
Size 7
170
6.69
513
20.20
174.2
6.86
50
136.89
5.39
160
6.3
1/4” BSP
B
A
F
E
C
D
