Page 61
6.5 Pump Lifting.
The Revolution pump has been designed with 4 Metric threaded locations on
each side of the gearbox for lifting the pump.
Note
1) These lifting point have been designed to carry the weight of the pump only, if
the pump has been installed / mounted these lifting point cannot be used.
2) On lifting two certified lifting eyes must be used in conjunction with a correctly
rated lifting sling
Horizontal Port
Vertical Ports
