Wright Flow Technologies Revolution R0150X - Page 24

Page 24
3.8.3.2 Frame 7
Horizontal Port Straight Flush Horizontal Circular Flush
Note: The liquid supply connections to flushed seals are made using the threaded ports on the sides of the
rotorcase. The pipe work should be arranged to provide an independent flush to each seal.
Vertical Straight Flush Vertical Circular Flush
Flush In
Flush In
Flush Out
Flush Out
Flush In
Flush Out
