Wright Flow Technologies Revolution R0150X - Page 57

Page 57
Fasteners & Torque Settings, continued
Description
Position
Size 6
Size 7
Button Cap Head Screw
Bearing Retainer
Qty / Pump
10
10
Size - mm
M12
M12
Torque - Nm
80
40
Torque – ft-lb
59
30
Locknut
Timing Gear / Shaft
Qty / Pump
2
2
Size - mm
M85 x 2
M105 x 2
Torque - Nm
140 - 180
260 - 280
Torque – ft-lb
160
200
Locknut
Inner Bearing/Shaft
Qty / Pump
N/A
4
Size - mm
M120 x 2
Torque - Nm
330 - 350
Torque – ft-lb
250
Socket Cap Head Screw
Feet
Qty / Pump
4
4
Size - mm
M16
M20
Torque - Nm
190
185
Torque – ft-lb
140
136
Socket Cap Head Screw
Rear Cover /
Qty / Pump
6
6
Gearbox
Size - mm
M12
M16
Torque - Nm
80
95
Torque – ft-lb
60
70
Hammer Drive Screw
Nameplate
Qty / Pump
4
4
