LF 170 Operation
89
ba54104e09 11/2010
4.4.2 Configuration setting table
General operating
instructions
The starting point for the settings is the start display of the configuration
level (see section 4.4.1):
Operation:
z All settings of the following setting table are run through step by
step.
z Select the desired value from the selection in each case with
<UP><DOWN> and confirm this with <ENTER>. After that you
reach the next setting.
z Certain settings or choices are only available with specific
instrument variants or depend on other preceding configuration
settings. Settings that are not available will be skipped.
z After running through all the settings you again reach the starting
point of the configuration level. From here change to the operating
level with <M> or <ESC> or go to the parameterization level with
<UP><DOWN>.
z In view mode you can change to the operating level from any point
with <M>.
Swap to the first setting with
<ENTER>.
