Wurtec S3 Communicator Master Station - Getting Started

Buy Online! Wurtec.com 3
1. Carefully open the shipping box and remove contents.
2. Inspect the telephone(s) for any damage.
3. Make sure the microphone, speaker and LED are connected correctly to the pins. See
drawing for locations.
If there is any damage call us for advice at 800-837-1066 or call our tech line at 419-930-1066
Telephone Line
Intercom Out to Phones
External 12-24 VAC/DC
Earth Ground Isolated
Program Keys
Battery (BAT)
Microphone (MIC)
LED (LED1)Speaker (SPK)
Getting Started
