Page 2 of 42 pages
Content
SUBJECT
Page
INDEX
3
1. BASICS
6
1.1. Instrument's overview 6
1.2. Measuring instruments / External display instruments 7
1.3. Measuring procedure / general use 8
1.3.1
Basic set-up of the inclination measuring instruments / plus - minus rule 8
1.3.2 Absolute measurement / Relative measurement / Differential measurement
9
1.3.3
General remarks about "ANGLES" 10
1.3.4
Height related to the step length 11
1.4. Zero setting by reversal measurement (Absolute ZERO) 12
1.5. Applications 12
1.5.1 Measuring absolute
12
1.5.2 Measuring relative
12
1.5.3 Differential respectively reference measurement using an engineer set
13
1.5.4 Angular measurements
15
1.5.5 Lines and flatness measurement (manual procedure)
16
1.6. WYLER software LEVELSOFT 17
2. DETAILED INFORMATION to the various instruments
19
2.1. MINILEVEL / LEVELTRONIC „classic“ 19
2.1.1 MINILEVEL “classic” A10 / LEVELMETER C25/DC (red cover)
19
2.1.2 LEVELMETER C25 / DC
20
2.1.3 LEVELTRONIC “classic” A40 / LEVELMETER 25 (blue cover)
22
2.1.4 LEVELMETER 25
22
2.2. MINILEVEL / LEVELTRONIC „NT“ 24
2.2.1 MINILEVEL “NT” 11 / LEVELMETER C25 (red cover) or
LEVELMETER 2000
24
2.2.2 LEVELMETER C25/DC
25
2.2.3 LEVELMETER 2000
26
2.2.4 LEVELTRONIC “NT” 41 with LEVELMETER C25/DC (red cover) or
LEVELMETER 2000
31
2.2.5 LEVELMETER C25/DC
32
2.2.6 LEVELMETER 2000
33
3. TECHNICAL DATA
38
3.1. LEVELTRONIC “classic” / A40 38
3.2. LEVELTRONIC “NT” / 41 38
3.3. MINILEVEL “classic” / A10 38
3.4. MINILEVEL “NT” / 11 39
4. MAINTENANCE
39
4.1. Easily cured difficulties 39
5. ACCESSORIES / SPARE PARTS
41
6. STORING Instruments / Care and handling of the batteries
41/42
7. REPAIR OF MEASURING INSTRUMENTS
42
Änderungen / Modifications:
Datum / Date Geändert durch
Modified by
Beschreibung der Änderung
Description of modifications
5.9.2000 HEH Fig. 9 / Seite 11 neu
27.3.2001 HEH Data collection using ENTER key
10.1.2003 HEH/MO Index included, Levelsoft PRO, deactivation autom. shut off
2.4.2003 HEH New:Express Repair Service
