3. TECHNICAL DATA
3.1 LEVELTRONIC “classic” / A40
Sensitivity, 1 Digit =
1 µm/m
0.2 Arcsec
5 µm/m
1 Arcsec
10 µm/m
2 Arcsec
Measuring range +/- 1999 Digits 2 mm/m
400 Arctic
10 mm/m
2000 Arcsec
20 mm/m
4000 Arcsec
Limits of error <0.5 Full scale value (DIN 2276) max. 1% of the measured value, min.
0,05% of the F.S. value
Limits of error >0.5 Full scale value (DIN 2276) max. 1% of (2 x measured value - 0.5 x F.S. value)
External display within 3 Seconds
Zero adjustment LEVELMETER +/- 450 Digits
Analogue output on LEVELMETER 25 1 mV / Digit
Analogue output F.S. on LEVELMETER 25 +/- 2000 mV
Temperature influence /°C max. 0.1% of F.S. value
Operating temperature
Storage temperature
0....+40°C
-20....+70°C
3.2 LEVELTRONIC “NT” / 41
Sensitivity
1 µm/m
0.2 Arcsec
5 µm/m
1 Arcsec
10 µm/m
2 Arcsec
Measuring range 2 mm/m
400 Arcsec
10 mm/m
2000 Arcsec
20 mm/m
4000 Arcsec
Limits of error <0.5 Full scale value (DIN 2276) max. 1% of the measured value, min.
0,05% of the F.S. value
Limits of error >0.5 Full scale value (DIN 2276) max. 1% of (2 x measured value - 0.5 x F.S. value)
External display within 3 Seconds
Analogue output 1 mV / 1µm/m
1 mV / 0.2 Arcsec
1 mV / 5µm/m
1 mV / 1 Arcsec
1 mV / 10µm/m
1 mV / 2 Arcsec
Digital output RS485 asynchron / 9600 Baud, 7Bit, 2Stopbits, no parity
Temperature influence /°C max. 0.1% of F.S. value
External power supply + 5V DC, 20 mW
Operating temperature
Storage temperature
0....+40°C
-20....+70°C
3.3 MINILEVEL “classic” / A10
Sensitivity Range II, 1 Digit =
1 µm/m
0.2 Arcsec
5 µm/m
1 Arcsec
10 µm/m
2 Arcsec
Measuring range II +/- 1999 Digits 2 mm/m
400 Arcsec
10 mm/m
2000 Arcsec
20 mm/m
4000 Arcsec
Measuring and display range I +/- 1999 Digits 20 mm/m
4000 Arcsec
100 mm/m
20000 Arcsec
200 mm/m
40000 Arcsec
Measuring range II
Limits of error <0.5 Full scale value (DIN 2276)
Limits of error >0.5 Full scale value (DIN 2276)
max. 1% of the measured value, min.
0,05% of the F.S. value
max. 1% of (2 x measured value - 0.5 x F.S. value)
Measuring range I +/-500 Digit
Limits of error <0.25 Full scale value (DIN 2276)
Display range +/- 2000 Digit
Limits of error >0.25 Full scale value (DIN 2276)
max. 1% of the measured value, min.
0,05% of the F.S. value
Display range only
Display within 3 Seconds
Zero adjustment (Range II) +/- 500 Digit
Zero adjustment (Range I) +/- 50 Digits
Analogue output (100kOhm) 1 mV / Digit
Analogue output F.S. +/- 2000 mV
Temperature influence /°C max. 0.1% of F.S. value
Operating temperature
Storage temperature
0....+40°C
-20....+70°C
Lifetime Battery
Battery TYPE
250 Std
2 x TR-164
