Page 26 of 42 pages
2.2.3 LEVELMETER 2000
2.2.3.1 Start the LEVELMETER 2000
press, ON/MODE key. The measuring mode last used is now being restarted,
then a display appears.
2.2.3.2 Measurement absolute (1 Instrument only )
press repeatedly, until the cursor is positioned under SENSOR
confirm selection. Display is flashing.
press repeatedly until the required channel, e.g. "A" is displayed
confirm. The address is being searched
press to confirm displayed address
Displayed mode changes to ABSOLUTE respectively the last used mode
2.2.3.3 Differential Measurement (2 Instruments) as 2.2.3.2, but
press until "A-B" appears
2.2.3.4 ZERO Setting (absolute) using reversal measurement
After this procedure the instrument indicates the absolute inclination in relation to the centre of the earth
Condition:
Only one channel "A" or "B" active to be set to ZERO at a time. Select Channel „A or B“
Chose correct channel „A“ or „B“
press repeatedly, until the cursor is flashing under SENSOR
confirm selection.
press repeatedly until the required channel, "A" or "B" is displayed, flashing
confirm selection. The Levelmeter 2000 now searches the address of the
instrument connected.
confirm displayed address
Displayed mode changes to ABSOLUTE, respectively to the last set-up mode
Start reversal measurement
press repeatedly until the cursor is flashing under ZERO
confirm (Direction indicator flashing) and the previously stored ZERO offset is
displayed.
place the instrument on the designated position
press HOLD key to register the first measuring value.
The display shows -oooooo- for a few seconds. Then the measured value is
displayed and the cursor under ZERO is flashing again.
Turn the instrument by 180°
press again to register the second measuring value. The display shows -
oooooo- for a few seconds. Then the measured value is displayed and the
direction indicator on the display is flashing.
press ENTER, to accept the correction factor for this reversal measurement
