SpectraLight QC
4
Table of Contents
Introduction and Installation 5
Key Features 5
Unpacking 5
Recommendations for Placement 6
Viewing Booth Assembly 6
Installing Luminaire Into Light Booth 9
Overhead Luminaire Installation 11
Powering Up 13
Navigating the Screen 13
SpectraLight QC Software Utility 14
System Requirements 14
Software Installation 14
System Setup (ADMIN) 15
Owner Profile Setup (OWNER) 15
Primary System Settings (SYS) 16
Reset Lamp Hour Counter and Lifetime (RLAMP) 18
Create Operator Profiles (PROFL) 20
Moving Lamp Switch Order and Auto-Sequencing the Light Sources (SEL) 22
Edit Operator Profiles (OPER) 23
Date and Time Setup (TIME) 24
User Settings (USER) 25
Display System Information (INFO) 26
Daisy Chain Configuration Setup (CHAIN) 27
Operation 29
Selecting a Lamp Source 29
Auto Sequence 30
Display Adjustment 31
Sensor Display (for service only) 32
System Operating Language 32
Running System Reports 32
Remote Control Operation 35
Operation 35
Remote Address Code Table 35
Optional Control Box 36
Installation 36
Appendices 37
Service Information 37
Luminaire Repackaging 37
General Maintenance 37
Cleaning (visible dust and dirt significantly reduce light output) 37
Replacing the Lamps 40
Replacing the Fuse 41
Screen Messages 41
Troubleshooting 42
Specifications 43
Menu Screen Flowchart 44
Parts and Accessories 48
