SpectraLight QC
29
OPERATION
Selecting a Lamp Source
NOTE: Disable the “auto-off” feature by pressing and holding the DL, A, or HZ light source switch for 2
seconds. You will hear a second click and see Nonstop appear in the display screen.
The main menu consists of two screens for selecting lamp sources.
Momentarily pressing the MORE switch toggles between the two main menu screens.
Momentarily pressing a lamp source switch will turn on the lamp source. The source remains on until you select
another lamp source or press the lamp source switch again.
Daylight, Halogen, or Horizon lamps will also turn off if the “auto-off” time is reached (default time of 5 minutes).
This feature is helpful if a user leaves the booth with any of these three sources selected and does not switch to
another source. Refer User Settings in the Configuration to adjust the “auto-off” timer.
NOTE: Lamps will not operate until the date and time for the system are set. Refer to the Administrator section
earlier in the Manual for instructions.
Main Menu 1 Main Menu 2
Momentary Held
The Dim control allows you to increase or decrease the Lux or brightness of only the fluorescent and UV
lamp sources. The Tri Lux option allows to page through three predefined lux values set for the profile.
When a fluorescent or UV lamp is activated, continually press the up (▲) switch or down (▼) switch to increase
or decrease the output. When dimming occurs, any profile that was set will be exited and the name will disappear
from the main menu, unless the admin changes the selection.
NOTE: Dim control or Tri Lux must be selected as the “up/down keys” option in System Setting for this function.
Source specs (Kelvin, wattage)
down (▼
Dim + appears when the up
(▲
