X-Rite Macbeth Lighting SpectraLight QC User Manual

SpectraLight QC
5
INTRODUCTION AND INSTALLATION
The X-Rite SpectraLight QC (SPLQC) is a visual color evaluation system which provides selectable light sources.
Key Features
Seven light sources:
- DL (daylight): filtered tungsten halogen calibrated
CCT 5000K or 6500K
- HZ: calibrated tungsten halogen CCT 2300K
- A (Incandescent A): calibrated tungsten halogen
CCT 2856K
- FL1 (fluorescent): adjustable light levels
- FL2 (fluorescent): adjustable light levels
- FL3 (fluorescent): adjustable light levels
- UV: calibrated and adjustable UVA levels
Other features:
- Intelligent lamp power supply unit (PSU)
- Dimmable electronic ballasts (0-10V)
- Three configurable fluorescent light sources
- Built-in light sensors to monitor light levels
- Adjustable light levels and automatic lux control
- Handles for easy setup and hanging luminaires
- Easy handle diffuser with safety switch
- Easy to replace daylight lux attenuators (snap
in mechanism; optional accessory)
- Built-in real time clock
- Computer interface for control and monitoring
- Versatile user interface configurations in
English or Chinese
Unpacking
Your system packaging should contain all the items listed below. If any of these items are missing or damaged,
contact X-Rite or your Authorized Representative.
• SpectraLight QC luminaire
• USB interface cable
• AC line cord
• Remote control (optional)
• Daisy chain cable (optional)
• Viewing booth assembly (optional)
• Manuals & utilities CD
• Other documentation
Display and touchpad
Luminaire
handles/hangers (4)
Viewing booth
Power switch, fuse,
USB, and daisy chain
connections (under
front edge)
