RM200QC
9
EN
RM200QC can store a maximum of 350 sample measurements which are
stored in date & time order. When the limit of 350 stored records is reached
the oldest record is automatically deleted.
1. From the Color QC window, press the Enter button to display the Tag
window.
2. Voice Tag
To record a voice tag for the active color, select Record voice tag from
the list and press and hold the Enter button down. Speak into the
microphone located below the power button. When finished, release
the Enter button.
3. Text Tag
To add a text tag for the current sample, select Edit text tag from the list
and press Enter. Add your note with the virtual keyboard using the
Navigation control and Enter button. When finished, highlight OK on the
virtual keyboard and press the Enter Button.
4. Exit the Tag window by selecting Back from the list and pressing the
Enter button.
Enter
button
To Next Page
