RM200QC
5
EN
Language Selection
Select the language from the list by pressing the up and down sides of the
Navigation control. Refer to the Introduction section for button locations.
Instrument Calibration
1. To calibrate, position reference slider (10) over optics and press
Measure (3).
2. When finished, position reference slider (10) back to storage location
and press Enter (5).
Sample Measurement and Preview
1. To measure, lightly press and hold Measure button (3) and position
instrument on sample.
2. Press Measure firmly (3) to take measurement. View results (8).
(10)
(3)
(10)
(5)
(3)
(3)
(8)
To Next Page
