Accessing Charger Information
975-0188-01-01 2–15
• Bank 1 Charging Stage
• Bank 1 Battery Voltage
• Bank 1 Charger Current
• Bank 2 Highest level bank fault or warning (if present)
• Bank 2 Charging Stage
• Bank 2 Battery Voltage
• Bank 2 Charger Current
• Bank 3 Highest level bank fault or warning (if present)
• Bank 3 Charging Stage
• Bank 3 Battery Voltage
• Bank 3 Charger Current
Remote Display Reporting While Disabled
If AC power has been disconnected or if you have used the optional remote
display to disable the BC Series the unit is considered to be disabled. The
optional remote display is also disabled at this time.
While the BC Series is disabled, you may wish to see the present status of
the banks.
To view the present status of the banks:
◆ Press
ON/STANDBY on the optional remote display.
If AC power is disconnected, the optional remote display will show one
cycle (similar to the battery monitor cycle) for each bank that was qualified
as present and healthy during the last battery detection cycle. The optional
remote display will turn itself off after one complete cycle.
◆ Press
ON/STANDBY on the optional remote display to initialize another
cycle.
If AC power is connected, the BC Series will turn on, check which battery
banks are present and healthy, and begin charging.
While the BC Series is off, and a fault is present, the optional remote display
will turn itself on approximately once per minute to show the fault and then
turn itself off.
