Specifications
A–2 975-0188-01-01
Physical Specifications
Electrical Specifications
Dimensions Base unit: 367 mm x 240 mm x 106 mm
14.45 in. x
9.45 in. x 4.17 in.
Remote Display: 118 mm x 41 mm x 32 mm
4.65 in. x 1.6 in. x 1.26 in.
Weight 5.2 kg (11.5 lbs)
AC input connections Two color-coded No. 16 AWG wires (L, N) and one
No. 18 AWG (G) minimum 152 mm (6 in.) long in a separate
AC wiring enclosure with 21.3 mm (0.84 in.) hole provision for
connection of a ½ inch North American "trade size" cable clamp
or conduit hub or international PG 13.5 or PG16 or M20 gland
or cable strain relief fitting.
DC output connections Four right-angle M6 studs (3 positives and 1 common
negative) for battery cable ring terminals and one M6 mm DC
equipment ground
Number of battery bank outputs 3 isolated, independently controlled outputs
Nominal battery voltage 12 V units: 12 VDC
24 V units: 24 VDC
Normal operating output range 12 V units: 0 – 16 VDC
24 V units: 0 – 32 VDC
Nominal operating AC voltage 110 – 240 VAC
Rated DC output current (total) BC3012: 30 A (up to 15 V)
BC5012: 50 A (up to 15 V)
BC1524: 15 A (up to 30 V)
BC2524: 25 A (up to 30 V)
Absorption voltage (in VDC for
BC3012 and BC5012)
(Multiply VDC by 2 to get the
absorption voltage for BC1524
and BC2524)
50 °C (122 °F) 25 °C (77 °F) <0°C (32°F)
Flooded 13.7 14.4 15.1
Gel 13.5 14.2 14.9
AGM 13.8 14.3 14.8
Lead-calcium 14.8 15.5 16.0
