Features
975-0012-01-02 Rev A 1–3
AC Side
The AC side of the DR Inverter has one 30-amp breaker for pass-thru AC Input,
and one 30-amp (20 amp in certain models) breaker for charger AC input.
Figure 1-1
Front Panel Features
DC End
Front Panel Controls
and Indicators
Battery Caps
AC End
Battery Sense Port
COM Port
Figure 1-2
AC Side of the DR Inverter
30 Amp Breaker for
Pass-thru AC Input
20 or 30 Amp Breaker
for Charger AC Input
Cover plate is not shown
in this photo.
Ventilation Holes
