Specifications of the DR Inverter
975-0012-01-02 Rev A A–7
Table A-4
Environmental Specifications for the DR Inverter/Charger
a
a.Specifications subject to change without notice.
Model DR1512 DR2412 DR1524 DR2424 DR3624
Dimensions
b
b.Allows for hardware extensions such as mounting rails, DC terminals, and front panel controls.
8.5" w x 7.25" H x 21" D (21.6 cm W x 18.4 cm H x 54.6 cm D
Unit Weight 35 lbs (16 kg) 45 lbs (21 kg) 35 lbs (16 kg) 40 lbs (16 kg) 45 lbs (21 kg)
“E” Models 38 lbs (18 kg) N/A 39 lbs (18 kg) (45 lbs (21 kg) N/A
Ambient Temp Range (rated 0 to 25 °C):
Operating 0 °C to +50 °C
Storage -55 °C to +75 °C
Altitude:
Operating 15,000 feet
Non-operating 50,000 feet
Mounting Wall-mount (with 16" mounting centers)
Shelf Mount
