Specifications
A–6 975-0012-01-02 Rev A
Auto Low Battery
Protection enabled
11 V 11 V 22 V 22 V
DC Charger Rate
(Adjustable)
0 to 70 amps 0 to 35 amps 0 to 17.5 amps 0 to 70 amps
Common Specifications:
Voltage Regulation
(maximum)
± 5%
Voltage Regulation
(Typical)
±2. 5%
Waveform modified sine wave
Load Power Factor
(allowed)
0.5 to 1.0 (leading or lagging)
Adjustable Load
Sensing Range
5 watts minimum to 100 watts maximum
Series Operation NO
Force Air Cooling Variable speed fan
Automatic Transfer
Relay
20 amps
Number of Charging
Profiles
10
Three-stage Charging Yes (float, absorption, bulk)
Temperature Comp
Probe (BTS)
optional
Remote Control (RC8)
d
optional
a.Specifications subject to change without notice.
b.This is the minimum AC current required to obtain full pass-through and maximum battery charging.
c.Product may not meet voltage regulation specifications at other than "Input Nominal" at full-rated load.
d.Also compatible with the RC4.
Table A-3
Electrical Specifications for the DR Inverter/Charger
a
- 230 Vac/50 Hz Models
Model DR1512E DR1524E DR1548E DR2424E
