Xantrex DR1512W User Manual

Specifications of the DR Inverter
975-0012-01-02 Rev A A–3
DC Input Voltage
(nominal)
c
12.6 Vdc 12.6 Vdc 25.2 Vdc 25.2 Vdc 25.2 Vdc
DC Input Voltage
Range
10.8 to 15.5 Vdc 10.8 to 15.5 Vdc 21.6 to 31.0 Vdc 21.6 to 31.0 Vdc 21.6 to 31.0 Vdc
Auto Low Battery
Protection enabled
11 V 11 V 22 V 22 V 22 V
DC Charger Rate
(Adjustable)
0 to 70 amps 0 to 120 amps 0 to 35 amps 0 to 70 amps 0 to 70 amps
Common Specifications:
Voltage Regulation
(maximum)
± 5%
Voltage Regulation
(Typical)
±2. 5%
Waveform modified sine wave
Load Power Factor
(allowed)
0.5 to 1.0 (leading or lagging)
Adjustable Load
Sensing Range
5 watts minimum to 100 watts maximum
Series Operation Yes
Force Air Cooling Variable speed fan
Automatic Transfer
Relay
30 amps
Number of
Charging Profiles
10
Three-stage
Charging
Yes (float, absorption, bulk)
Temperature Comp
Probe (BTS)
optional
Remote Control
(RC8)
d
optional
a.Specifications subject to change without notice.
b.This is the minimum AC current required to obtain full pass-through and maximum battery charging.
c.Product may not meet voltage regulation specifications at other than "Input Nominal" at full-rated load.
d.Also compatible with the RC4.
Table A-1 Electrical Specifications for the DR Inverter/Charger
a
- 120 Vac/60 Hz Models
Model DR1512 DR2412 DR1524 DR2424 DR3624

Xantrex DR1512W Specifications

General

Brand	Xantrex
Model	DR1512W
Category	Inverter
Language	English
