Page #15 background image
Key Features
975-0390-01-01 15
Selectable Low Battery
Shutdown
The low battery shutdown for the inverter can be
manually selected by the user by choosing a low,
middle, or high setting. The low setting default for low
battery shutdown is10.5 volts except Freedom HF
1500 (PN: 806-1544).
Model PN
Shutdown
Settings (V)
Low Mid High
Freedom HF 1000 806-1020 10.5 n/a 11.8
Freedom HF 1055 806-1054 10.5 n/a 11.8
806-1054-01 10.5 n/a 11.8
806-1055 10.5 n/a 11.8
Freedom HF 1055
EMS
806-1055-02 10.5 n/a 11.8
Freedom HF 1500 806-1544, 806-1544-
01
12.1 12.1 12.1
Freedom HF 1800 806-1840 10.5 n/a 11.8
Freedom HF 1800
T
806-1840-01, 806-
1840-04
10.5 11.8 11.8
806-1840-03 12.1 12.1 12.1
806-1840-05 11.8 12.1 12.1
some 806-1840-01 10.5 n/a 11.8
Freedom HF 1800
EMS
806-1840-02 10.5 n/a 11.8
Battery-friendly
Charging
For the inverter to perform effectively, the batteries
must be charged correctly. The Freedom HF hasa
built-in three-stage charging system that extends the
life and optimizesthe performance of the batteries. In
addition to the numerous features which let you
maximize your battery’s life and performance, the
Freedom HFunlike many chargersalso has the
ability to recharge a near-zero voltage
e
battery and an
ignition-switched 20-amp auxiliary 12-volt power
source
f
.
Ignition Control The Freedom HF features the ability to inhibit the
inverter from operating in the absence of a voltage
signal from a vehicle's ignition circuit. Thisis particularly
useful if the inverter isrequired to operate only when a
vehicle's engine isrunning.
e
Near-zero or dead batteries can be recharged. However, some batteries which have been left uncharged
for days can become severely damaged thus, recharging is futile.
f
Available on the Freedom HF 1055 EMS model and Freedom HF 1800 EMS model. The inverter/charger
features a 20-amp fused and switched output voltage supplied from the inverter/charger's positive terminal.
When connected to a vehicle's ignition signal, a switched positive voltage is available to power auxiliary
circuits that are required to operate only when the vehicle is operational.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xantrex Freedom HF and is the answer not in the manual?

Xantrex Freedom HF Specifications

General IconGeneral
Output Voltage120 VAC
Output Frequency60 Hz
Input Voltage12 VDC
WaveformModified Sine Wave
Surge Power3600W
Operating Temperature0°C to 40°C
Efficiency90%
Protection FeaturesOverload, Over temperature, Short circuit
