Configuration
975-0390-01-01 25
Viewing Inverter/Charger Information
The LED screen displays inverter/charger information as well as
feature settings in coordination with the LED lights underneath the
screen.
n Press the Select button to toggle between the following
information:
Info and Setting LED Screen
Info and Settings
LED
DC Input Voltage
12.8 (example)
Solid Input Voltage (V)
DC Input Current
11 (example)
Solid Input Current (A)
AC Output Power
0.85 (example)
Solid Output Power (kW)
Charging Current
Setting
a
2A or 10A or 20A
none
Charging Current
Setting
b
5A or 15A or 35A or
55A
none
Charging Current
Setting
c
2A or 10A or 20A or
40A
none
Inverter Mode Setting
IN0 or IN1
none
Alarm Setting
aL0 or AL1
none
a
Settings available only for Freedom HF 1000 (PN: 806-1020).
b
Settings available only for Freedom HF 1055 (PNs: 806-1054, 806-1054-01, 806-1055, 806-1055-02).
c
Settings available only for Freedom HF 1500 and 1800 models (PNs: 806-1544, 806-1840, 806-1840-01,
806-1840-02, 806-1840-03, 806-1840-05).
Info and Setting LED Screen
Info and Settings
LED
Low Voltage Setting
d
sdL or sdn or sdH
none
d
The middle setting Sdn is available only for Freedom HF 1500 and 1800 T models (PNs: 806-1544, 806-
1840, 806-1840-01, 806-1840-03), 806-1840-05. This setting is not available for some Freedom HF 1800 T
(PN: 806-1840-01).
