Page #54 background imageLoading...
Page #54 background image
54 975-0390-01-01
5 SPECIFICATIONS
NOTE: Specifications are subject to change without prior notice.
Physical Specifications
1000-
wattModels
1500|1800-watt
Models
L × W × H 15.5” (393mm)×
9.5” (241mm)×
4.2” (106mm)
18” (457mm)×
9.5” (241mm)×
4.2” (106mm)
Net Weight 10 lbs (4.5 kg) 12.8 lbs (5.8 kg)
NOTE: Excludes any external
AC or DC wiring harnesses
included on some models.
Environmental
Specifications
1000-
wattModels
1500|1800-watt
Models
Ambient Temperature:
Operating Temperature Range 0–40 ºC -20–60 ºC
with output derated above 25 °C
Storage Temperature Range -40–70 ºC
Humidity: Operation/Storage 5–95% RH, non-condensing
System Specifications
1000-
wattModels
1500|1800-watt
Models
Transfer relay rating 30A, 2.0hp
Transfer time <30ms (milliseconds)
Transfer on bad voltage
90–100V for low AC and 130–140 for high
AC
Cooling
Fan, activated by any of the following:
High internal temperature
High AC output power
