Xantrex Freedom HF User Manual

975-0390-01-01 55
NOTE:These specifications refer to inverter mode.
DC Input
1000-wattModels
1500|1800-watt
Models
Operating voltage range for all
models including some Freedom
HF 1800 T (806-1840-01)
10.5–15.5 VDC (low
limit)
11.8–15.5 VDC
(high limit)
10.5–15.5 VDC (low
limit)
11.8–15.5 VDC
(high limit)
Operating voltage range for
Freedom HF 1500 and Freedom
HF 1800 T (806-1840-01, 806-
1840-03, 806-1840-04, 806-
1840-05)
n/a 10.5–15.5 VDC (low
limit)
11.8–15.5 VDC
(mid limit)
12.1–15.5 VDC
(high limit)
Safe non-operating voltage range 0–16 VDC 0–16 VDC
Nominal voltage for all models 12.5 VDC 12.5 VDC
Nominal current at fullload 100 ADC 180 ADC
AC Output
1000-
wattModels
1500|1800-watt
Models
Output voltage 115 VAC 115 VAC
Continuous power 1.0kW @ 25 °C 1.8kW @ 25 °C 1.5kW
@ 25 °C (Freedom
HF 1500 only)
Surge power 17 AAC (2kW for
200 ms)
30 AAC (3.6kW for
300 ms)
Max short-circuit current 55 AAC peak 55 AAC peak
Frequency 60 Hz 60 Hz
AC Output
1000-
wattModels
1500|1800-watt
Models
Wave shape Modified Sine
Wave
Modified Sine Wave
Power derating above 40 °C
ambient temp
See Invert Power Derating vs. Ambient
Temperature on page 41.
Peak efficiency ≥87% ≥87%
Full load efficiency ≥80% ≥80%
Other
1000-
wattModels
1500|1800-watt
Models
No load input power (producing
output voltage)
≤10W ≤10W
Off mode current draw
≤1mA ≤1mA

Xantrex Freedom HF Specifications

General

Output Voltage	120 VAC
Output Frequency	60 Hz
Input Voltage	12 VDC
Waveform	Modified Sine Wave
Surge Power	3600W
Operating Temperature	0°C to 40°C
Efficiency	90%
Protection Features	Overload, Over temperature, Short circuit
