Xantrex Freedom HF User Manual

16 975-0390-01-01
2 FEATURES
This section identifies the default settings and the hardware
features of the Freedom HF Inverter Charger.
Table 1 lists the default settings for the Freedom HF system.
You may record your settings in the right-hand column after you
have configured the Freedom HF.
Item Default Setting Your Setting
Alarm* ON
Charger Current*
20 A (Freedom HF 1000 model)
55 A (Freedom HF 1055 models)
40 A (Freedom HF 1500 models)
40 A (Freedom HF 1800 models)
Battery Type ** Flooded(14.4/13.5)
* adjustable from the display panel.
** adjustable from the main unit behind the display panel assembly.
Table 1Freedom HF Default Values

Xantrex Freedom HF Specifications

General

Output Voltage	120 VAC
Output Frequency	60 Hz
Input Voltage	12 VDC
Waveform	Modified Sine Wave
Surge Power	3600W
Operating Temperature	0°C to 40°C
Efficiency	90%
Protection Features	Overload, Over temperature, Short circuit
