Xantrex Freedom HF User Manual

3 OPERATION
This section includes descriptions of the different modes and
settings of the Freedom HF Inverter Charger. This section
includes:
Configuration 24
Setting Battery Types on the Main Unit 24
Viewing Inverter/Charger Information 25
Adjusting Feature Settings 26
Display Panel Operation 29
Operating in Shore Power Mode 30
Operating in Inverter Mode 31
Inverter Mode Setting is ON (“Standby”) 31
Turning the Inverter Function On and Off 31
Inverter Mode Setting is OFF 32
Energy Saver 25-hour Automatic Shut Off 32
Status LED During Inverter Mode 32
Checking Battery Status 33
Checking Output Power 33
Operating During Transition Between Shore Power and
Inverter Mode 34
Transitioning from Shore Power to Inverter Mode 34
Transitioning from Inverter Mode to Shore Power 34
Operating Limits 35
Inverter Loads 36
Battery Charging 38
Routine Maintenance 40
Inverter Overload Operation 41
Invert Power Derating vs. Ambient Temperature 41
975-0390-01-01 23

Xantrex Freedom HF Specifications

General

Output Voltage	120 VAC
Output Frequency	60 Hz
Input Voltage	12 VDC
Waveform	Modified Sine Wave
Surge Power	3600W
Operating Temperature	0°C to 40°C
Efficiency	90%
Protection Features	Overload, Over temperature, Short circuit
