Installation Tools and Materials
975-0799-01-01 15
Installation Tools and Materials
You will need the following to install the Freedom XC PRO:
n Wire stripper
n Mounting (#2) screws or bolts
n #2 Phillips torque screwdriver
n Torque wrench for DC terminals (½" or 13mm socket
wrench)
n AC cable (that is, two-conductor-plus-ground cable), sized
appropriately for load and application
n ½" (or ¾") trade-size strain relief clamps (for the AC cable
clamp holes)
n Wire nuts or crimp connectors if installing the 20-pin
Communications Harness (PN: 808-0820) (sold separately)
n DC cable, sized appropriately for load and application
n Lugs for DC cables to fit
5
/
16
" DC stud terminals as well as
appropriate tools (like a crimping tool)
n AC and DC disconnects and over-current protective devices
