Xantrex SOLAR CHARGE CONTROLLER 30 User Manual

Depending on the battery type, these voltage settings are set according
to charging stages.
Parameter
Default
AGM (SEL) 6EL FLD LFP
Over-voltage fault 16V 16V 16V 14.8V
Maximum charge voltage 15V 15V 15V 14.6V
Over-voltage fault recovery 15V 15V 15V 14.5V
Equalize voltage 14.6V -- 14.8V 14.4V
Absorption voltage 14.4V 14.2V 14.6V 14.4V
Float voltage 13.8V 13.8V 13.8V 13.4V
Re-bulk voltage 13.2V 13.2V 13.2V 13.3V
Absorption time 120m 120m 120m 30m
Equalize time 120m -- 120m 30m
Temperature compensation
coefficient (mV/C/2V)
-3 -3 -3 0
NOTE: For 24Vlead-acid batteries, multiplythe voltage
valueshere bytwo.
Table 6Battery Voltage Default Settings
975-1012-01-01 Rev B
Oct 2019
29
