Truecharge™ 2 Battery Charger
975-0402-01-01 1–5
This guide for use by qualified installers only
4 Fuse access panel cover provides access to the DC fuse
in the event of an accidental reverse battery polarity
installation.
Disconnect the batteries and AC power before opening
the fuse access panel.
5 AC wiring compartment cover provides the installer
with easy access to the AC wiring compartment, to
allow for a trouble free installation. Remove and replace
when installing the product.
6 DC ground stud for connecting the charger’s chassis to
ground.
Item Description
WARNING: Shock hazard
