Electrical Specifications
975-0402-01-01 A–3
This guide for use by qualified installers only
Electrical Specifications
AC Input Specifications
AC input voltage range Nominal: 120 Vac, 230 Vac, 240 Vac
Full Performance: 104 – 265 Vac ±4 Vac
Automatic derating to 80% output: 90 – 108 ±4 Vac
Maximum AC input
current
at 104 Vac at 230 Vac – 20%
TC1012: 2.5 A TC1012: 1.25 A
TC1512: 3.5 A TC1512: 1.9 A
TC2012: 4.5 A TC2012: 2.5 A
TC3012: 7.0 A TC3012: 3.7 A
TC4012: 9.0 A TC4012: 5 A
TC5012: 11.5 A TC5012: 6.2 A
TC6012: 13.5 A TC6012: 7.8 A
TC1524: 7.0 A TC1524: 3.8 A
TC2024: 9.0 A TC2024: 5 A
TC3024: 13.5 A TC3024: 7.5 A
TC5024: 22.5 A TC5024: 12.5 A
Power factor at rated load ≥0.95
Frequency 47 – 63 Hz
Efficiency – peak 12 Vdc units: 77% @ 120 Vac, 80% @ 230 Vac
24 Vdc units: 85% @ 120 Vac, 87% @ 230 Vac
Surge protection Line-to-neutral surge protector rated at 275 Vac
