Installation
2–14 975-0402-01-01
This guide for use by qualified installers only
Mounting the Truecharge™ 2 Battery Charger
Mount the Truecharge™ 2 Battery Charger using all four
mounting slots and holes which are provided. Mounting
orientations a) and b) in Figure 2-2 meet IP-32 and drip-proof
requirements that are needed to ensure safety in the presence
of condensation. The other possible mounting orientations c)
and d) also shown in Figure 2-2 will not prevent the entry of
dripping water, and are not suitable for use in marine
installations or other moist environments without the
installation of additional drip protection. They are only
acceptable for use in locations that are always dry.
To mount the Truecharge™ 2 Battery Charger:
1. Select a mounting surface that is flat and allows for a
minimum of 10 cm (4 in.) of clearance on the top and
bottom ends for air flow and at least 6 cm (2.5 in.) of
clearance on either sides (see Figure 2-3, “Ventilation
Clearance” on page 2–7).
2. Drill the four pilot holes for the mounting screws, taking
care that there is nothing behind the surface that can be
damaged by the drill.
3. Mount the Truecharge™ 2 Battery Charger using
corrosion resistant, #6 (3 mm) round, pan head (or
similar) screws.
The top two keyhole-style mounting holes can be used to
hold the Truecharge™ 2 Battery Charger in place while
fastening the bottom two screws. For secure, permanent
mounting, use the holes in all four mounting flanges and
fasten all four screws. Do not rely on screws only in the
keyhole slots for the installation of the charger.
