Installation
2–26 975-0402-01-01
This guide for use by qualified installers only
Mounting the Optional Remote Panel
To mount the remote panel:
1. Choose a location for the remote panel that is within
15 m (50 ft.) from the charger. Use only the
six-conductor communications cable (RJ-12) that came
with the remote panel.
2. Use the mounting template provided with the Remote
Panel to predrill mounting holes.
Take care that there is nothing behind the surface for you
to damage such as other cables or pipes.
3. Connect the RJ-12 connector to the remote panel and
route it to the charger. Be careful not to damage the
connector locking tab when routing the cable. You can
use some tape to protect the locking tab from catching on
something and breaking off when routing the cable.
4. Once the Truecharge™ 2 Battery Charger is mounted,
plug the other RJ-12 connector into the Remote port on
the rear panel of the Truecharge™ 2 Battery Charger.
Note: The RJ-12 communications cable used for the remote
panel uses six conductors. The sensor cable for the BTS on the
other hand, uses four conductors – an RJ-11 cable.
