Specifications
A–4 975-0402-01-01
This guide for use by qualified installers only
DC Output Specifications
Number of isolated battery
bank outputs
TC1012:
1 output
TC1512:
2 separated outputs
TC2012, TC3012, TC4012, TC5012, TC6012,
TC1524, TC2024, TC3024, TC5024:
3 separated outputs
DC output voltage range
including dead battery
charging voltage
12 Vdc units: 0 – 15.5 Vdc
24 Vdc units: 0 – 31 Vdc
Maximum equalization
voltage
12 Vdc units: 16 Vdc
24 Vdc units: 32 Vdc
Voltage accuracy (no load) 12 Vdc units:
±0.1 Vdc at 14.4 Vdc @ 25 °C (77 °F)
24 Vdc units:
±0.2 Vdc at 28.8 Vdc @ 25 °C (77 °F)
Nominal battery voltage 12 Vdc units:12 Vdc
24 Vdc units:24 Vdc
Normal operating output
range
12 Vdc units: 0 – 16 Vdc
24 Vdc units: 0 – 32 Vdc
Maximum DC output current
(total)
TC1012: 10 +10% A
TC1512: 15 +10% A
TC2012: 20 +10% A
TC3012: 30 +10% A
TC4012: 40 +10% A
TC5012: 50 +10% A
TC6012: 60 +10% A
TC1524: 15 +10% A
TC2024: 20 +10% A
TC3024: 30 +10% A
TC5024: 50 +10% A
