If material is not dumping on the paper,
the problem
is the interface between the
Developer and the Xerographic Module
(DRS).
0
0
Remove the Xerographic Module
and check the Drum to Auger
Seal. The seal should be against
the Photoreceptor Drum. If not
reform, or replace. The seal
should point towards the Charge
Corotron.
Check the Photoreceptor Drum
for an out of round condition,
Slowly rotate the Drum and
watch the surface in relationship
with
the straight edge of the
Xerographic Module.
if the
distance changes, remove the
Photoreceptor Assembly and
check the hubs for damage and
reseat the Photoreceptor.
Ensure that the fuser roll
is
adequately oiled
Obtain the DRS Tool and
instructions from the District
Technical Specialist and check
the
DRS.
8/96
OF 4 Toner/Developer Dumping 2-80 x1nn51 ri
