SETTING UP THE FIERY EXP4110 FROM THE CONTROL PANEL
23
Fiery EXP4110 Control Panel
Use the Fiery EXP4110 Control Panel to view status information, print system pages,
and set up printing. While most elements in the Control Panel have counterparts in
Command WorkStation, you can view current functions on the Control Panel even
when Command WorkStation is not connected to the Fiery EXP4110 or is not running.
Safety warnings
The Fiery EXP4110 display window is a liquid crystal display (LCD) made of glass, and it
can break. Do not subject it to strong shocks.
If the display window breaks and the liquid crystal material leaks out, do not inhale, ingest,
or touch it. If the material gets on your skin or clothing, wash it off with soap and water
immediately.
Do not touch or put pressure on the display window. This will change the color of
the window.
Activity light
The activity light indicates the current Fiery EXP4110 activity. If the light is:
1Up button
2 Menu button
3Down button
4Activity light
5 Line selection buttons
6 Display window
1
2
3
4
5
6
Solid red An error has occurred, causing the Fiery EXP4110 to be
disabled.
Flashing red An error has occurred, causing printing to be disabled, but the
Fiery EXP4110 is capable of processing.
Solid green The Fiery EXP4110 is idle.
Flashing green The Fiery EXP4110 is processing or printing a job, or
communicating with a remote computer.
No light The Fiery EXP4110 is off or starting up.
