Xerox DocuMate 6480 User Manual

Maintenance Xerox
®
DocuMate
®
6460 / 6480
User Guide 35
6. Close the scanner when you’re finished.
Replacing the Separation Roller
The roller will wear out and is designed to be a user-replaceable part. A worn roller can cause
documents to feed in skewed at an angle, or multiple pages to feed at the same time. Before
replacing the roller you should clean it as excessive dust on the roller will make it appear worn and
smooth. You cannot properly diagnose a worn roller until you have cleaned it. You should generally
replace the roller between 80,000 and 100,000 scans.
Replacement parts can be purchased from the Parts & Accessories page for your scanner at
www.xeroxscanners.com
.
1. Open the scanner.
2. Locate the roller cover in the ADF door.

Xerox DocuMate 6480 Specifications

General

Media thickness (min)	1.25 mm
Maximum scan area (ADF)	216 x 5994 mm
Minimum scan area (ADF)	51 x 51 mm
Scanning media types supported	Photo paper, Plastic Card
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	75 - 90 g/m²
Scanner type	ADF scanner
Product color	Blue, White
Built-in display	Yes
Auto document feeder (ADF) input capacity	120 sheets
Film scanning	No
Maximum scan size	241 x 5994 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	80 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	160 ipm
Sensor type	CCD
Scan drivers	ISIS, TWAIN, WIA
Daily duty cycle (max)	10000 pages
USB version	3.2 Gen 1 (3.1 Gen 1)
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)
Cables included	AC, USB
Minimum RAM	2048 MB
Minimum processor	Intel Pentium IV
Minimum storage drive space	350 MB
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Sustainability certificates	ENERGY STAR
Power supply type	AC
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	168 mm
Width	316 mm
Height	191 mm
Weight	4700 g
