Main Components and Functions 31
No. Name Description
11 Parallel connector (option) Installing a Parallel Port (option) allows connection of a Centronics interface
cable.
12 USB 2.0 connector Allows connection of a USB 2.0 cable.
13 Ethernet connector Allows connection of a 10Base-T/100Base-TX Ethernet interface cable.
14 Expansion device connector Allows connection of expansion devices supported by the printer.
15 Power cord connector Connects the power cord to the printer.
11
13
12
15
14
Back
