Xerox® Phaser® 3020 Printer Service Manual
Product Specifications
General Procedures and Information
Product Specifications
Table 1 Product Overview
Feature Phaser 3020
Speed 20 ppm (A4), 21 ppm (8.5 x 11 in.)
Print Resolution 1200 x 1200 dpi
Processor 600MHz
Printer Language Emulation SPL
Memory M2022W / M2022: 128MB
M2020W: 64MB
M2020: 8MB
Interface High Speed USB 2.0
Network 802.11b/g/n Wireless LAN (Only
M202xW)
Wireless Model Supports NFC Printing.
Print Cartridge - Initial 700 Images
Print Cartridge - Standard 1500 Images
Table 2 General Print Engine Specifications
Item Mode Phaser 3020
Engine Speed Simplex 20 ppm (A4), 21 ppm (8.5 x 11 in.)
Warm-up time From Sleep Mode Less Than 30 Seconds
FPOT From Standby Mode Less Than 8.5 Seconds
From Sleep Mode Less Than 19 Seconds
Resolution 1200 x 1200 dpi
Table 3 Controller and Software
Item Specification
Processor 600 MHz
Memory 128 MB
Printer Languages GDI
Fonts Windows
Print Driver Default Driver SPL
Install SPL
Supporting OS Windows® XP (32/64bits)
Windows® Vista(32/64bits)
Windows® 2003 (32/64bits)
Windows® 2008 (32/64bits)
c7 (32/64bits)
Windows® 2008 R2 (64bits)
Windows® 7 & 8 (32/64bits)
Linux
RedHat Enterprise Linux 5, 6
Fedora 11-19
SuSE Linux 10.0, 11 (32 bit)
Open SuSE 11.0, 11.1, 11.2, 11.3, 11.4,
12.1, 12.2, 12.3
Ubuntu 10.04, 10.10, 11.04, 11.10, 12.04,
12.10, 13.04
SuSE Linux Enterprise Desktop 10, 11
Debian 5.0, 6.0, 7.0, 7.1
Mint 13, 14, 15
Mac OS X 10.5 - 10.9
WHQL Windows® Vista 7, 8 (32/64bits)
Compatibility Windows® 2000/ XP (32/64bits)
Windows® Vista(32/64bits)
Windows® 2003 Server (32/64bits)
Windows® 2008 Server (32/64bits)
Windows® 7 (32/64bits)
Windows® 2008 Server R2 (64bits)
Windows® 8 (32/64bits)
Network Interface Parallel
USB
Wired Network
Wireless Network
NA
Hi-Speed USB 2.0
NA
802.11b/g/n Wireless LAN
Applications Easy Printer Man-
ager
Windows® and Macintosh® OS Only
Printer Status Windows® OS Only
Smart Panel Linux Only

Xerox Phaser 3020 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	GDI
Total input capacity	150 sheets
Total output capacity	100 sheets
Paper tray media types	Glossy paper, Matte paper
Maximum ISO A-series paper size	A4
Wi-Fi	Yes
Network ready	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	SNMP, WPA2
Mobile printing technologies	Apple AirPrint, Xerox PrintBack
Supported network protocols (IPv4)	IPSec, IPv4, IPv6, SNMPv3, WPA2
Standard interfaces	USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	128 MB
Processor frequency	600 MHz
Maximum internal memory	- MB
Product color	Blue, White
Power consumption (standby)	37 W
Power consumption (printing)	313 W
Power consumption (PowerSave)	2.3 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	RedHat EL Linux 5.0, RedHat EL Linux 5.1, RedHat EL Linux 5.2, RedHat EL Linux 5.3, RedHat EL Linux 6.0, SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11, Ubuntu 10.04, Ubuntu 10.10, Ubuntu 11.04, Ubuntu 11.10, Ubuntu 12.04, Ubuntu 12.10, Ubuntu 13.04
Server operating systems supported	Windows Server 2003, Windows Server 2012
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	215 mm
Width	331 mm
Height	188 mm
Weight	4100 g
