Xerox Phaser 6500 - Rear View; Internal Components

Features
Phaser 6500 Color Laser Printer
User Guide
19
Rear View
Internal Components
1. Power switch
2. Power cord connector
3. USB Port
4. Network connector
5. Optional memory slot
Phaser 6500DN Printer
1. Imaging unit
2. Fuser
3. Transfer belt unit with Tray 1 removed so the transfer belt unit folds down completely
4. Duplex unit
5. Button for opening the front cover and releasing the duplex unit
p6500-002
5 43 2 1
p6500-003
2
1
5
4
3
