Paper Feed Performance in Trays 6 and 7
If misregistration or skew occurs on printed output that was fed from Trays 6 or 7, manual
adjustment of the paper-feed levers may improve and correct the printed output.
Important: For most print jobs, these levers should remain in their default position. The
position of these levers should be changed only if there is a skew problem when running a
specific print job or media type. Changing the levers can cause more skew problems when
running certain media types such as coated, label, tab stock, hole-punched paper, transparency,
film, postcards, and envelopes.
The paper-feed adjustment levers are found in Trays 6 and 7. These levers are used to improve paper
feed accuracy and to reduce paper skew problems.
1. Rear Paper-feed Adjustment Lever 2. Right-side Paper-feed Adjustment Lever
IImmpprroovviinngg PPaappeerr FFeeeedd PPeerrffoorrmmaannccee iinn TTrraayyss 66 aanndd 77
1. Open the tray by pulling it out slowly until it stops.
2. Ensure that the desired paper is loaded into the tray.
3. Go to the PredictPrint Media Manager application on the print server. On the Tray Properties
window, verify the correct paper information, such as size, type, weight, and paper curl or
alignment option for the tray.
