12. To close the transfer drawer, grasp handle 2 and gently push in the drawer completely (1), then
turn the green handle to the left to lock the drawer in place (2).
13. Close the left and center front doors completely. The press does not operate when doors or covers
are open.
CClleeaarriinngg JJaammss iinn AArreeaass 33,, 44,, aanndd 55
Important: Before opening any press doors, ensure that the press has stopped printing.
1. Open the right front door.
2. Open lever 3a upward (1) and remove any jammed paper (2).
48
Xerox
®
Versant
®
4100 Press
Quick Start Guide
Troubleshooting
