Maintenance
176 WorkCentre 7800 Series Multifunction Printer
User Guide
Cleaning the Printer Interior
Cleaning the Printhead Lenses
The printer is constructed with four printhead lenses. Clean all lenses as described in the following
procedure.
CAUTION: Do not perform this procedure when the printer is copying or printing.
1. Open the front cover of the printer.
2. Turn the orange lever to the left.
3. Pull the drum cartridge cover down until it clicks into the open position.
To Next Page
