Xerox WorkCentre 7800 series

Troubleshooting
WorkCentre 7800 Series Multifunction Printer 223
User Guide
9. Close door A, then close tray 5.
Clearing Jams at Door B
1. Open tray 5 as shown (1).
2. While lifting the release lever (2), open door B as shown (3).
3. Remove the jammed paper as shown.
Note: If the paper is torn, remove all torn pieces from the printer.
4. Close door B, then close tray 5.
