Xilinx VCU128 User Manual

Table 31: J18 VITA 57.4 FMCP HSCP Connections (cont'd)
J18
FMCP
HSCP
Pin
Schematic
Net Name
I/O
Standard
FPGA
(U1)
Pin
J18
FMCP
HSCP
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1)
Pin
J18 Sections Y/Z Connections to FPGA U1
Y2 FMCP_HSPC_DP23_C2M_P LVDS AE44 Z1 FMCP_HSPC_PRSNT_M2C_B
Y3 FMCP_HSPC_DP23_C2M_N LVDS AE45 Z4 FMCP_HSPC_DP22_C2M_P LVDS AF46
Y6 FMCP_HSPC_DP21_C2M_P LVDS AG44 Z5 FMCP_HSPC_DP22_C2M_N LVDS AF47
Y7 FMCP_HSPC_DP21_C2M_N LVDS AG45 Z8 FMCP_HSPC_DP20_C2M_P LVDS AG48
Y10 FMCP_HSPC_DP10_M2C_P LVDS AR53 Z9 FMCP_HSPC_DP20_C2M_N LVDS AG49
Y11 FMCP_HSPC_DP10_M2C_N LVDS AR54 Z12 FMCP_HSPC_DP11_M2C_P LVDS AP51
Y14 FMCP_HSPC_DP12_M2C_P LVDS AN53 Z13 FMCP_HSPC_DP11_M2C_N LVDS AP52
Y15 FMCP_HSPC_DP12_M2C_N LVDS AN54 Z16 FMCP_HSPC_DP13_M2C_P LVDS AN49
Y18 FMCP_HSPC_DP14_M2C_P LVDS AM51 Z17 FMCP_HSPC_DP13_M2C_N LVDS AN50
Y19 FMCP_HSPC_DP14_M2C_N LVDS AM52 Z20 FMCP_HSPC_GBTCLK5_M2C_
P
LVDS AG40
Y22 FMCP_HSPC_DP15_M2C_P LVDS AL53 Z21 FMCP_HSPC_GBTCLK5_M2C_
N
LVDS AG41
Y23 FMCP_HSPC_DP15_M2C_N LVDS AL54 Z24 FMCP_HSPC_DP10_C2M_P LVDS AR48
Y26 FMCP_HSPC_DP11_C2M_P LVDS AR44 Z25 FMCP_HSPC_DP10_C2M_N LVDS AR49
Y27 FMCP_HSPC_DP11_C2M_N LVDS AR45 Z28 FMCP_HSPC_DP12_C2M_P LVDS AP46
Y30 FMCP_HSPC_DP13_C2M_P LVDS AN44 Z29 FMCP_HSPC_DP12_C2M_N LVDS AP47
Y31 FMCP_HSPC_DP13_C2M_N LVDS AN45 Z32 FMCP_HSPC_DP16_M2C_P LVDS AL49
Y34 FMCP_HSPC_DP17_M2C_P LVDS AK51 Z33 FMCP_HSPC_DP16_M2C_N LVDS AL50
Y35 FMCP_HSPC_DP17_M2C_N LVDS AK52 Z36 FMCP_HSPC_DP18_M2C_P LVDS AJ53
Y38 FMCP_HSPC_DP19_M2C_P LVDS AH51 Z37 FMCP_HSPC_DP18_M2C_N LVDS AJ54
Y39 FMCP_HSPC_DP19_M2C_N LVDS AH52 Z40 UTIL_3V3
More informaon about the VITA 57.4 FMC+ specicaon is available on the VITA FMC
Markeng Alliance website.
Board Power System
[Figure 2, callout 34]
The VCU128 board has an Intersil power system. The following gure shows the VCU128 board
power system block diagram.
Chapter 3: Board Component Descriptions
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 85
Send Feedback
