Xilinx VCU128 User Manual

• I2C bus
• Status LEDs
• User I/O (1 x push-buon switch, 8 x LED)
• VITA 57.4 FMC+ HSPC connector (DP[0:23], LA[0:33])
• Power management with I2C voltage monitoring through Intersil power controllers and GUI
• Conguraon opons:
○ Quad SPI ash memory
○ USB JTAG I/F (FTDI FT4232HL)
○ Plaorm cable USB II interface 2x7 2 mm keyed connector
Board Specifications
Dimensions
Height: 7.53 inch (19.14 cm)
Length: 9.50 inch (24.13 cm)
Thickness (±5%): 0.061 inch (0.1549 cm)
Note: A 3D model of this board is not available.
IMPORTANT
! The VCU128 board height exceeds the standard 4.376-inch (11.15 cm) height of a
PCI Express
®
card.
Environmental
Temperature
Operang: 0°C to +45°C, Storage: -25°C to +60°C
Humidity
10% to 90% non-condensing
Operating Voltage
+12 VDC
Chapter 1: Introduction
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 8
Send Feedback
