Xilinx VCU128 User Manual

Chapter 2
Board Setup and Configuration
Electrostatic Discharge Caution
CAUTION! ESD can damage electronic components when they are improperly handled, and can result
in total or intermient failures. Always follow ESD-prevenon procedures when removing and replacing
components.
To prevent ESD damage:
• Use an ESD wrist or ankle strap and ensure that it makes skin contact. Connect the equipment
end of the strap to an unpainted metal surface on the chassis.
• Avoid touching the adapter against your clothing. The wrist strap protects components from
ESD on the body only.
• Handle the adapter by its bracket or edges only. Avoid touching the printed circuit board or
the connectors.
• Put the adapter down only on an anstac surface such as the bag supplied in your kit.
• If you are returning the adapter to Xilinx
®
Product Support, place it back in its anstac bag
immediately.
Board Component Location
The following gure shows the VCU128 board component locaons. Each numbered component
shown in the gure is keyed to the table in Board Component Descripons.
IMPORTANT! The board component locaons gure is for visual reference only and might not reect
the current revision of the board.
IMPORTANT! There could be mulple revisions of this board. The specic details concerning the
dierences between revisions are not captured in this document. This document is not intended to be a
reference design guide and the informaon herein should not be used as such. Always refer to the
schemac, layout, and XDC les of the specic VCU128 version of interest for such details.
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 9
Send Feedback
