Chapter 3
Board Component Descriptions
Overview
This chapter provides a detailed funconal descripon of the board’s components and features.
Table 1 idenes the components, references the respecve schemac page numbers, and links
to the corresponding detailed funconal descripon in this chapter. Component locaons are
shown in Figure 2.
Component Descriptions
Virtex UltraScale+ XCVU37P-2FSVH2892E Device
[Figure 2, callout 1]
The VCU128 board incorporates the VU37P high bandwidth memory (HBM) FPGA, which
ulizes stacked silicon interconnect (SSI) technology to add HBM die next to the FPGA die on the
package substrate. The VCU128 board is populated with the Virtex
®
UltraScale+™
XCVU37P-2FSVH2892E device. For more informaon on Virtex UltraScale+ FPGAs, see Virtex
UltraScale+ FPGA Data Sheet: DC and AC Switching Characteriscs (DS923).
Encryption Key Battery Backup Circuit
The XCVU37P device U1 implements bitstream encrypon key technology. The VCU128 board
provides the encrypon key backup baery circuit shown in the following gure.
Chapter 3: Board Component Descriptions
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 18
Send Feedback
