Xilinx VCU128 User Manual

References
The most up to date informaon related to the VCU128 board and its documentaon is available
on the following websites.
VCU128 Evaluaon Kit
VCU128 Evaluaon Kit - Master Answer Record 71849
These documents provide supplemental material useful with this guide:
1. Virtex UltraScale+ FPGA Data Sheet: DC and AC Switching Characteriscs (DS923)
2. UltraScale Architecture Conguraon User Guide (UG570)
3. UltraScale Architecture SelectIO Resources User Guide (UG571)
4. UltraScale Architecture-Based FPGAs Memory IP LogiCORE IP Product Guide (PG150)
5. UltraScale Architecture Clocking Resources User Guide (UG572)
6. UltraScale Architecture GTY Transceivers User Guide (UG578)
7. UltraScale FPGAs Transceivers Wizard LogiCORE IP Product Guide (PG182)
8. UltraScale Devices Gen3 Integrated Block for PCI Express LogiCORE IP Product Guide (PG156)
9. Tri-Mode Ethernet MAC LogiCORE IP Product Guide (PG051)
10. AXI UART Lite LogiCORE IP Product Guide (PG142)
11. Vivado Design Suite User Guide: Using Constraints (UG903)
12. UltraScale Architecture PCB Design User Guide (UG583)
13. Silicon Labs CP210x USB-to-UART Installaon Guide (UG1033)
14. VCU128 System Controller Tutorial (XTP534)
15. VCU128 Soware Install and Board Setup Tutorial (XTP535)
16. VCU128 Restoring Flash Tutorial (XTP533)
17. For addional documents associated with Xilinx devices, design tools, intellectual property,
boards, and kits see the Xilinx documentaon website.
These websites provide supplemental material useful with this guide:
18. Xilinx, Inc.
(XCVU37P-2FSVH2892E)
19. Micron Technology
(MT40A512M16LY-075E, MT44K32M36RB-083E, MT25QU02GCBB8E12-0SIT)
20. hp://www.cypress.com (CY7C4142KV13_106FCXC)
Appendix D: Additional Resources and Legal Notices
UG1302 (v1.0) December 21, 2018 www.xilinx.com
VCU128 Board User Guide 98
Send Feedback
