Chapter 3: Board Component Descriptions
AB29 DDR4_DQ32 G2 DQL0 U100
AB30 DDR4_DQ33 F7 DQL1 U100
AC29 DDR4_DQ34 H3 DQL2 U100
AD32 DDR4_DQ35 H7 DQL3 U100
AC31 DDR4_DQ36 H2 DQL4 U100
AE30 DDR4_DQ37 H8 DQL5 U100
AC28 DDR4_DQ38 J3 DQL6 U100
AE29 DDR4_DQ39 J7 DQL7 U100
AC27 DDR4_DQ40 A3 DQU0 U100
AA27 DDR4_DQ41 B8 DQU1 U100
AA28 DDR4_DQ42 C3 DQU2 U100
AB28 DDR4_DQ43 C7 DQU3 U100
W27 DDR4_DQ44 C2 DQU4 U100
W29 DDR4_DQ45 C8 DQU5 U100
W28 DDR4_DQ46 D3 DQU6 U100
V27 DDR4_DQ47 D7 DQU7 U100
AA32 DDR4_DQ48 G2 DQL0 U2
AA33 DDR4_DQ49 F7 DQL1 U2
AA34 DDR4_DQ50 H3 DQL2 U2
AE34 DDR4_DQ51 H7 DQL3 U2
AD34 DDR4_DQ52 H2 DQL4 U2
AB31 DDR4_DQ53 H8 DQL5 U2
AC34 DDR4_DQ54 J3 DQL6 U2
AC33 DDR4_DQ55 J7 DQL7 U2
AA30 DDR4_DQ56 A3 DQU0 U2
Y30 DDR4_DQ57 B8 DQU1 U2
AA31 DDR4_DQ58 C3 DQU2 U2
W30 DDR4_DQ59 C7 DQU3 U2
Y33 DDR4_DQ60 C2 DQU4 U2
W33 DDR4_DQ61 C8 DQU5 U2
W34 DDR4_DQ62 D3 DQU6 U2
Y34 DDR4_DQ63 D7 DQU7 U2
AN24 DDR4_DM0 E7 DML_B/DBIL_B U101
AM29 DDR4_DM1 E2 DMU_B/DBIU_B U101
Table 3-3: DDR4 Component Memory Connection to XCZU7EV PS Bank 504 (Cont’d)
XCZU7EV (U1)
Pin
Net Name
DDR4 Component Memory
Pin # Pin Name Ref. Des.
