FPGA Mezzanine Card Interface
[Figure 2-1, callout 25]
The ZCU104 evaluation board supports the VITA 57.1 FPGA mezzanine card (FMC)
specification [Ref 19] by implementing the LPC connector (J5). LPC connectors use a 10 x 40
form factor, partially populated with 160 pins. The connector is keyed so that a mezzanine
card, when installed in the FMC LPC connector on the ZCU104 evaluation board, faces away
from the board
FMC LPC Connector J5
[Figure 2-1, callout 25]
The FMC connector at J5 implements the full FMC LPC connectivity:
• 68 single-ended, or 34 differential user-defined pairs (34 LA pairs: LA[00:33])
• One GTH transceiver DP differential pair
• Two GBTCLK differential clocks
• 61 ground and 10 power connections
The ZCU104 board FMC VADJ voltage for LPC connector J5 is determined by the
IRPS5401MTRPBF U180 voltage regulator described in Board Power System, page 83. Valid
values for the VADJ_FMC rail are 1.2V, 1.5V, and 1.8V. The LPC J5 connections to XCZU7EV
U1 are shown in Table 3-29 and Table 3-30.
P27 PS_MGTREFCLK1P GTR_REF_CLK_SATA_C_P
(1)
37 Q5
8T49N287 U182
P28 PS_MGTREFCLK1N GTR_REF_CLK_SATA_C_N
(1)
36 NQ5
M27 PS_MGTREFCLK2P GTR_REF_CLK_USB3_C_P
(1)
27 Q2
M28 PS_MGTREFCLK2N GTR_REF_CLK_USB3_C_N
(1)
28 NQ2
M31 PS_MGTREFCLK3P GTR_REF_CLK_DP_C_P
(1)
23 Q3
M32 PS_MGTREFCLK3N GTR_REF_CLK_DP_C_N
(1)
23 NQ3
Notes:
1. Series capacitor coupled.
2. MGT connections I/O standard not applicable.
Table 3-28: PS-GTR Bank 505 Interface Connections (Cont’d)
XCZU7EV
(U1) Pin
XCZU7EV Pin Name Schematic Net Name
(2)
Connected To
Pin No. Pin Name Device
